Materials of Manufacture​ | |
Filter media | ePTFE |
Membrane support | Polypropylene |
Irrigation mesh (support) | Polypropylene |
Drainage Layer | Polypropylene |
Inner core | Polypropylene |
End fittings | Polypropylene |
Outer Support | Polypropylene |
Support ring | Stainless steel |
Sealing | Fusion bonding |
Cartridge Dimensions | |
diameter | 70mm |
lenght | 64 or 136mm |
Grades | 0.2µm @ Beta5000 (99,98%) |
Guaranteed microbial rating in a liquid challenge |
BorsoVent cartridges are validated for bacterial removal in liquids in accordance with PDA, HIMA guidelines and ASTM F838-05, with a log reduction value >7. This test is stringent in comparison to an airborne particulate challenge test. |
Adapters and O-ring | 1/2"BSP male thread |
Silicone O-ring (Other matarial available on request) | |
Cartridge Treatment | |
Standard | Cleand and Flushed with pyrogen-free water. |
Rinsed | Ultra-clean, pulse flushed to give a system resistivity of 18MΩ.cm |
Additional information | |
All BorsoVent cartridges and seals are approved according to: FDA 21 CFR 177 EC Directive 1935/2004 USP class VI |
De BorsoPTFe Membraan filterkaarsen zijn een alternatief op de Membraan filterkaarsen van:
Parker
Pall
Milipore
